1-60mm PVC foam board pvc hard rigid plastic board for furniture

Name: 1-60mm PVC foam board pvc hard rigid plastic board for furniture
Brand: JINBAO
Rating: 5.0 (81 reviews)


Availability:



Inquire

JINBAO 1-60mm PVC Foam Boards are the ultimate waterproof alternative to plywood and MDF. Engineered with a high-density "Celuka" core for screw retention and structural stability. Ideal for kitchen cabinets, bathroom vanities, and construction templates. Termite-proof, lead-free, and paintable.

Model:
PVC Foam Boards
Brand:
JINBAO

Jinbao Technology Group Catalog.pdf

ISO9001-2015

Download

RoHS Certificate of Compliance – PVC Foam Board

CE Attestation of Conformity – PVC Foam Board

Looking for a reliable supplier? [ Contact Us Today ] for a quote.

Product Description

1-60mm PVC Foam Board – The Waterproof "Plastic Plywood" for Furniture

Introduction

For furniture manufacturers and construction firms seeking a moisture-proof alternative to wood, Jinan Jinbao Plastic Co., Ltd. presents our High-Density Rigid PVC Foam Board.

Available in thicknesses from 1mm to 60mm, this "Celuka" grade sheet combines the lightweight properties of foam with the surface hardness of solid plastic. Unlike MDF or plywood which swell and rot in humidity, JINBAO’s PVC boards are 100% waterproof and termite-proof, making them the global standard for "wet area" cabinetry (kitchens, bathrooms) and outdoor construction.

Key Features

100% Waterproof: Absolutely no water absorption; prevents swelling, delamination, and mold growth in humid environments.
High Screw Holding Power: High-density core (0.55-0.9 g/cm³) ensures excellent screw retention, comparable to wood.
Termite & Pest Proof: Inorganic composition makes it impervious to termites, borers, and fungal decay.
Fire Retardant: Self-extinguishing (Class B1) rating; does not drip or spread fire.
Easy Fabrication: Can be cut, drilled, nailed, screwed, and glued using standard woodworking tools.
Eco-Friendly: Lead-free, non-toxic, and 100% recyclable; no formaldehyde emissions like engineered wood.

Technical Specifications

Specification	Details
Material	Rigid PVC Foam (Celuka / Co-extruded)
Thickness	1mm – 60mm (Popular: 3mm, 5mm, 12mm, 15mm, 18mm)
Standard Size	4' x 8' (1220x2440mm) \| Custom sizes available
Density	0.4 g/cm³ – 0.9 g/cm³ (Furniture Grade usually 0.55+)
Surface Finish	Hard Smooth Satin / Glossy / Textured (Wood grain available)
Color	Snow White (Standard), Black, Grey, Wood Grain
Hardness	Shore D 45-75 (Depending on density)
Certifications	ISO 9001, CE, SGS, RoHS, REACH

Applications

Furniture Manufacturing: Kitchen cabinets, bathroom vanities, wardrobes, and lockers.
Construction: Concrete formwork (reusable 50+ times), wall partitioning, and flooring underlayment.
Transportation: Interior fit-outs for RVs, caravans, boats, and buses (lightweighting).
Advertising: Thick signage letters, exhibition stands, and photo mounting boards.

Why Choose JINBAO PLASTIC?

Furniture Grade Density: We specialize in high-density boards (0.55-0.65 g/cm³ for 18mm) specifically designed to hold hinges and screws securely, solving the "loose screw" issue of cheaper foam boards.
Massive Production: With 15 dedicated PVC lines, we produce over 1,500 tons monthly, ensuring stable supply for large furniture factories.
Advanced Celuka Technology: Our cooling calibration process creates a hard, scratch-resistant "skin" on both sides of the sheet, providing a superior finish for painting or laminating.
Custom Lamination: We can laminate PVC film (wood grain, marble, solid colors) directly onto the foam board, saving you a processing step.

公司实力-2

Certification

◇ Certifications that our cast Acrylic sheet obtained: SGS, CE, ISOcertificate. pvc发泡板证书

Packing & Delivery

1) one side clear pe film protect the pvc foam
2) about 3pcs or 5pcs ,10pcs use one pe film bag
3) with pallet Bulk cargo packing: 1.5 tons per pallet, use wooden pallets, hard corner protector

Packing & Delivery

Frequently Asked Questions (FAQ)

Q: Can I use screws directly into this board?

A: Yes, for furniture thickness (12mm-18mm), provided you choose a density of 0.55 g/cm³ or higher. Lower density boards (0.4) are for advertising and may not hold screws well.

Q: Is it paintable?

A: Yes, PVC foam board can be painted with PVC-compatible acrylic or urethane paints. It creates a smooth, professional finish.

Q: Can it replace plywood for concrete formwork?

A: Absolutely. Our high-density construction grade (often blue or black) can be reused 50+ times, releases easily from concrete without oil, and doesn't swell.

Q: What is the standard thickness for cabinets?

A: The global standard for cabinet carcasses is 15mm to 18mm. We stock these in 4x8ft specifically for the cabinet industry.
